Fuel Tube Assemblies

A fuel line is a hose used to bring fuel from one point in a vehicle to another or from fuel storage tank

to engine inlet.
Fuel lines are designed to contain liquid fuel or fuel vapor.
This includes all hoses or tubing for the filler neck, for connections between under floor piping,
and for connecting a carbon canister to the fuel tank

The fuel tube is made of high performance nylon material with end quick connectors fitted at both ends.
The construction of the fuel tubes material consists of the following types:

Monolayer fuel lines

Single layer wall nylon tube with good chemical and mechanical properties.
Common used material are PA11 or PA12. Suitable for fuel lines with medium permeation requirement.


Fuel Tube Assy-Pipe Assy Drain	Fuel Tube Assy-Roll Over Valve	Fuel Tube Assy-Roll Over Valve c/w tube vapor	Fuel Tube Assy-Tube Feed	Fuel Tube Assy-Tube Main	Fuel Tube Assy-Tube Purge	Fuel Tube Assy-Tube Return


Fuel Tube Assy-Tube Vapor	Fuel Tube Assy-Under Floor Fuel Piping	Fuel Tube Assy-Under Floor Fuel Piping(close up)	Corrugated Fuel Lines-Leveling Hose	Corrugated Fuel Lines-Neck Assy Filler

Multilayer fuel lines (EVX306)
A unique 3 layers wall thickness tube developed with technology from EMS Switzerland. The 3 layers consist of outer PA12 material,
barrier layer of EVOH and inner layer of PA6 material delivering exceptional toughness and corrosion resistance.
Suitable for fuel lines system with low permeation requirement and fuel with ethanol content up to 100%.

COLD IMPACT TEST	SAE (-40°C/454g)	VW (-40°C/500g)	VW (-40°C/800g)
EMS-EVX 306	No Break	No Break	No Break

After Ageing	Sourgas PN90/40°C/1000h	DIN 73378 (23°C)	Heat aging 150°C/200h(23°C)
EMS-EVX 306	No Break	No Break	No Break

Elongation @ break	Original (100mm/min)	Cross (25mm/min)	SAE (50mm/min)
EMS-EVX 306	>210%	250 - 280%	>250%

Permeation test	SAE 1737 60°C/2bar/CM 15(g/day*m²)
EMS-EVX 306	80

The end fitting design can be in:
a. Quick connector or spool – A. Raymond
b. metal coupling or adaptors
c. End beads (connected with short rubber hose with constant pressure clips) - for vapor lines only

Operating condition:
- Working pressure up to 20 bars
- Burst pressure up to 60 bars
- Pull off force up to 250N
- Temperature 140 degree C peak. However, special high temperature grade material is available for higher temperature requirement.

Chemtube fuel lines provide:
- Medium to low permeation rating with high performance barrier properties
- Good chemical resistance
- Excellent mechanical properties
- Long-term aging and durability
- Flexibility
- Good impact strength at low temperature

Corrugated fuel lines (Fuel filler)
Made of advanced high precision corrugation technology with choice of monolayer or multilayer constructions.
Suitable for fuel filler hose and breather hose application. Corrugated hose length and shape can be customized to suit customer requirement.
