TB8-P Series Automatic Booster Pump



Applications:

Deal for pumping clean , non -volatile liquids without fibers or solids in such application as:

 Homes where the incoming city water supply pressure is tool low

 portable water supply or underground

 lrrigation

 Washing/Cleaning system

Product Features:
Mannufactured with non-corrosive rust proof material
Special design corrosive resistant pressure tank with good appearance.
Approprilate reliable check valve with silent operation.
compact design, small size ,easy installation.
Every pumps tested in our factory to ensure quality and reliability
High performance , electricity saving motor with patented cooling construction .Build-in thermal overload protector for motor burnt out protection.

Operation Conditions:
Amblent temperature:Max.+4 °C
Liquid temperature:+40C ~+40 °C
suction head:Max.8 m
Inlet pressure : Lower then the pressure switch OFF setting. (see specification)
