Application:
The WALRUS TPCK Series is vertical multistage
centrifugal pump, designed for industrial use,
specially for machine tools, to carry fluids such
as water, coolant, light oil and other clean, non
aggressive matters.
- Industrial circulation system
- Washing/cleaning system
- Filtration system
|
Pump Construction:
Immersible vertical multistage centrifugal pump,
self-priming, coupling connection between pump
and motor, stainless steel construction design
ensures corrosion-free operation.
Motor:
Nominal speed : 2860 or 3450 rpm
Frequency range : 50 or 60 Hz
Standard voltages : 3Ø 198-242 / 342-418V
Enclosure class : IP54
Insulation class : F.
Operation Conditions :
Ambient temperature : Max. +40¢XC
Liquid temperature range : +0¢XC~+90¢XC
Operating pressure : Max. 30 kg/cm²
Submerged depth : Min. 65mm
Model Code:
Dimension:
TPCK2T Series, 50Hz
| Model |
Power
(kW) |
Phase |
Voltage |
Ampere |
| TPCK2T13-13 |
1.5
|
3
|
198-242/342-418
|
6.2-5.1/3.6-2.9
|
| TPCK2T15-15 |
1.5
|
3
|
198-242/342-418
|
6.2-5.1/3.6-2.9
|
| TPCK2T18-18 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK2T19-19 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK2T22-22 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK2T26-26 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
TPCK2T Series, 60Hz
| Model |
Power
(kW) |
Phase |
Voltage |
Ampere |
| TPCK2T13-13 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
| TPCK2T15-15 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
| TPCK2T18-18 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
| TPCK2T20-20 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
TPCK4T Series, 50Hz
| Model |
Power
(kW) |
Phase |
Voltage |
Ampere |
| TPCK4T8-8 |
1.5
|
3
|
198-242/342-418
|
6.2-5.1/3.6-2.9
|
| TPCK4T10-10 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK4T12-12 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK4T14-14 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
| TPCK4T16-16 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
| TPCK4T19-19 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
| TPCK4T22-22 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
TPCK4T Series, 60Hz
| Model |
Power
(kW) |
Phase |
Voltage |
Ampere |
| TPCK4T5-5 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK4T6-6 |
2.2
|
3
|
198-242/342-418
|
8.9-7.3/5.1-4.2
|
| TPCK4T8-8 |
3.0
|
3
|
198-242/342-418
|
11.4-9.3/6.6-5.4
|
| TPCK4T10-10 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
| TPCK4T12-12 |
4.0
|
3
|
198-242/342-418
|
16.6-13.6/9.6-7.9
|
