ADEX Series
5 Port Solenoid Valve A05, 12, 20 Series Features:
3 Port Solenoid Valve A00 Series Features:
Body width remains the same, but the flow rate 1.5 to 3 times more than conventional valves
ADEX Series — PR Series
Double solenoid arranged on both sides of main valve
» Read More …
ADEX Series — GF Series
Double solenoid arranged on the same side of main valve
» Read More …
ADEX Series — 00S Series
» Read More …
ADEX Series — PR Series
5 Port Pilot Operated Solenoid Valve A05P Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A05PS25
|
Sub-base mounting
|
5
|
Single
|
2
|
Rc1/8
|
5.8
|
0.15~0.7
(1.5~7)
|
|
A05PD25
|
Double
|
0.1~0.7
(1~7)
|
|
A05PD35
|
3•Closed center
|
4.5
|
0.2~0.7
(2~7)
|
|
A05PE35
|
3•Exhaust center
|
|
A05PO35
|
3•Pressure center
|
6.7
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A05R Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A05RS25
|
In-line mounting
|
5
|
Single
|
2
|
M5
|
4
|
0.15~0.7
(1.5~7)
|
|
A05RD25
|
Double
|
0.1~0.7
(1~7)
|
|
A05RD35
|
3•Closed center
|
3.7
|
0.2~0.7
(2~7)
|
|
A05RE35
|
3•Exhaust center
|
|
A05RO35
|
3•Pressure center
|
4.5
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A05P/R
.
|
Type of Manifold
|
For A05P Series
|
For A05R Series
|
|
MFC☐-A05P
|
MFS☐-A05P
|
MFX☐-A05P
|
MFU☐-A05R
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side Compact type
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external pilot, Pilot valve captured exhaust A & B ports on side Compact type
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc⅛
|
Rc⅛
|
Rc⅛
|
Rc⅛
|
|
A & B port
|
M5, C4, C6
|
Rc⅛
|
Rc⅛,C4, C6
|
M5, C4, C6
|
|
Y port
|
—
|
—
|
M5
|
—
|
|
X port
|
—
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A05PS25
A05PD25
A05PD35
A05PE35
A05PO35
|
A05PS25
A05PD25
A05PD35
A05PE35
A05PO35
|
A05PS25X
A05PD25X
A05PD35X
A05PE35X
A05PO35X
|
A05RS25
A05RD25
A05RD35
A05RE35
A05RO35
|
|
Blank plate
|
A05P-BP
|
A05R-BP
|
5 Port Pilot Operated Solenoid Valve A12P Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A12PS25
|
Sub-base mounting
|
5
|
Single
|
2
|
Rc1/4
|
11.1
|
0.15~0.7
(1.5~7)
|
|
A12PD25
|
Double
|
0.1~0.7
(1~7)
|
|
A12PD35
|
3•Closed center
|
7.6
|
0.2~0.7
(2~7)
|
|
A12PE35
|
3•Exhaust center
|
|
A12PO35
|
3•Pressure center
|
14.1
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A12R Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A12RS25
|
In-line mounting
|
5
|
Single
|
2
|
Rc1/8
|
8.8
|
0.15~0.7
(1.5~7)
|
|
A12RD25
|
Double
|
0.1~0.7
(1~7)
|
|
A12RD35
|
3•Closed center
|
8.5
|
0.2~0.7
(2~7)
|
|
A12RE35
|
3•Exhaust center
|
|
A12RO35
|
3•Pressure center
|
12
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A12P/R
.
|
Type of Manifold
|
For A12P Series
|
For A12R Series
|
|
MFS☐-A12P
|
MFX☐-A12P
|
MFU☐-A12R
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external Pilot, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc¼
|
Rc¼
|
Rc¼
|
|
A & B port
|
Rc¼, C6, C8
|
Rc¼, C6, C8
|
Rc⅛, C6, C8
|
|
Y port
|
—
|
M5
|
—
|
|
X port
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct Mount
|
|
Mountable Solenoid Valve
|
A12PS25
A12PD25
A12PD35
A12PE35
A12PO35
|
A12PS25X
A12PD25X
A12PD35X
A12PE35X
A12PO35X
|
A12RS25
A12RD25
A12RD35
A12RE35
A12RO35
|
|
Blank plate
|
A12P-BP
|
A12R-BP
|
5 Port Pilot Operated Solenoid Valve A20P Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A20PS25
|
Sub-base mounting
|
5
|
Single
|
2
|
Rc1/4、 Rc3/8
|
20.6
|
0.15~0.7
(1.5~7)
|
|
A20PD25
|
Double
|
0.1~0.7
(1~7)
|
|
A20PD35
|
3•Closed center
|
15.9
|
0.2~0.7
(2~7)
|
|
A20PE35
|
3•Exhaust center
|
|
A20PO35
|
3•Pressure center
|
20.5
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A20R Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A20RS25
|
In-line mounting
|
5
|
Single
|
2
|
Rc1/4
|
17.6
|
0.15~0.7
(1.5~7)
|
|
A20RD25
|
Double
|
0.1~0.7
(1~7)
|
|
A20RD35
|
3•Closed center
|
15.7
|
0.2~0.7
(2~7)
|
|
A20RE35
|
3•Exhaust center
|
|
A20RO35
|
3•Pressure center
|
18.1
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A20P/R
.
|
Type of Manifold
|
For A20P Series
|
For A20R Series
|
|
MFS☐-A20P
|
MFX☐-A20P
|
MFU☐-A20R
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external pilot, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc¼
|
Rc¼
|
Rc¼
|
|
A & B port
|
Rc¼, C8, C10
|
Rc¼, C8, C10
|
Rc¼, C8, C10
|
|
Y port
|
—
|
M5
|
—
|
|
X port
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A20PS25
A20PD25
A20PD35
A20PE35
A20PO35
|
A20PS25X
A20PD25X
A20PD35X
A20PE35X
A20PO35X
|
A20RS25
A20RD25
A20RD35
A20RE35
A20RO35
|
|
Blank plate
|
A20P-BP
|
A20R-BP
|
ADEX Series — GF Series
5 Port Pilot Operated Solenoid Valve A05G Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A05GD25
|
Sub-base mounting
|
5
|
Double
|
2
|
Rc1/8
|
5.8
|
0.1~0.7
(1~7)
|
|
A05GD35
|
3•Closed center
|
4.5
|
0.2~0.7
(2~7)
|
|
A05GE35
|
3•Exhaust center
|
|
A05GO35
|
3•Pressure center
|
6.7
|
● Voltage/DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A05F Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A05FD25
|
In-line mounting
|
5
|
Double
|
2
|
M5
|
4
|
0.1~0.7
(1~7)
|
|
A05FD35
|
3•Closed center
|
3.7
|
0.2~0.7
(2~7)
|
|
A05FE35
|
3•Exhaust center
|
|
A05FO35
|
3•Pressure center
|
|
4.5
|
● Voltage/DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A05G/F
.
|
Type of Manifold
|
For A05G Series
|
For A05F Series
|
|
MFC☐-A05G
|
MFS☐-A05G
|
MFX☐-A05G
|
MFU☐-A05F
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side Compact type
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external pilot, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc⅛
|
Rc⅛
|
Rc⅛
|
Rc⅛
|
|
A & B port
|
M5, C4, C6
|
Rc⅛
|
Rc⅛, C4, C6
|
M5, C4, C6
|
|
Y port
|
—
|
—
|
M5
|
—
|
|
X port
|
—
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A05GS25
A05GD25
A05GD35
A05GE35
A05GO35
|
A05GS25
A05GD25
A05GD35
A05GE35
A05GO35
|
A05GS25X
A05GD25X
A05GD35X
A05GE35X
A05GO35X
|
A05FS25
A05FD25
A05FD35
A05FE35
A05FO35
|
|
Blank plate
|
A05P-BP
|
A05R-BP
|
5 Port Pilot Operated Solenoid Valve A12G Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A12GD25
|
Sub-base mounting
|
5
|
Double
|
2
|
Rc1/4
|
11.1
|
0.1~0.7
(1~7)
|
|
A12GD35
|
3•Closed center
|
7.6
|
0.2~0.7
(2~7)
|
|
A12GE35
|
3•Exhaust center
|
|
A12GO35
|
3•Pressure center
|
|
14.1
|
● Voltage/DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A12F Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A12FD25
|
In-line
mounting
|
5
|
Double
|
2
|
Rc1/8
|
8.8
|
0.1~0.7
(1~7)
|
|
A12FD35
|
3•Closed center
|
8.5
|
0.2~0.7
(2~7)
|
|
A12FE35
|
3•Exhaust center
|
|
A12FO35
|
3•Pressure center
|
|
12
|
● Voltage/DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A12G/F
.
|
Type of Manifold
|
For A12G Series
|
For A12F Series
|
|
MFS☐-A12G
|
MFX☐-A12G
|
MFU☐-A12F
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external pilot, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc¼
|
Rc¼
|
Rc¼
|
|
A & B port
|
Rc¼, C6, C8
|
Rc¼, C6, C8
|
Rc⅛, C6, C8
|
|
Y port
|
—
|
M5
|
—
|
|
X port
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A12GS25
A12GD25
A12GD35
A12GE35
A12GO35
|
A12GS25X
A12GD25X
A12GD35X
A12GE35X
A12GO35X
|
A12FS25
A12FD25
A12FD35
A12FE35
A12FO35
|
|
Blank plate
|
A12P-BP
|
A12R-BP
|
5 Port Pilot Operated Solenoid Valve A20G Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A20GD25
|
Sub-base
mounting
|
5
|
Double
|
2
|
Rc1/4、
Rc3/8
|
20.6
|
0.1~0.7
(1~7)
|
|
A20GD35
|
3•Closed center
|
15.9
|
0.2~0.7
(2~7)
|
|
A20GE35
|
3•Exhaust center
|
|
A20GO35
|
3•Pressure center
|
20.5
|
● Voltage/DC24V
● Wiring/Plug-in connector
5 Port Pilot Operated Solenoid Valve A20F Series
Pilot Operate/ Rubber seal
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A20FD25
|
In-line
mounting
|
5
|
Dobule
|
2
|
Rc1/4
|
17.6
|
0.1~0.7
(1~7)
|
|
A20FD35
|
3•Closed center
|
15.8
|
0.2~0.7
(2~7)
|
|
A20FE35
|
3•Exhaust center
|
|
A20FO35
|
3•Pressure center
|
18.1
|
● Voltage/DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MF☐-A20G/F
.
|
Type of Manifold
|
For A20G Series
|
For A20F Series
|
|
MFS☐-A20G
|
MFX☐-A20G
|
MFU☐-A20F
|
|
common P, common R, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Common external pilot, Pilot valve captured exhaust A & B ports on side
|
common P, common R, Pilot valve captured exhaust A & B ports on valve body
|
|
Port size
|
P & R port
|
Rc¼
|
Rc¼
|
Rc¼
|
|
A & B port
|
Rc¼, C8, C10
|
Rc¼, C8, C10
|
Rc¼, C8, C10
|
|
Y port
|
—
|
M5
|
—
|
|
X port
|
—
|
M5
|
—
|
|
Number of stations
|
2~20
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A20GS25
A20GD25
A20GD35
A20GE35
A20GO35
|
A20GS25X
A20GD25X
A20GD35X
A20GE35X
A20GO35X
|
A20FS25
A20FD25
A20FD35
A20FE35
A20FO35
|
|
Blank plate
|
A20P-BP
|
A20R-BP
|
ADEX Series — 00S Series
3 Port Direct Operated Solenoid Valve A00S Series
Direct Operate/ Poppet
|
Model No
|
Mounting
|
Port
|
Solenoid
|
Position
|
Port size
|
Effective
area
(mm2)
|
Pressure
range
MPa
(kgf/cm2)
|
|
A00SC23
|
Sub-base mounting
|
3
|
Single
|
2•NC
|
M3
|
0.14
|
0~0.7
(0~7)
|
|
A00SC23J
|
0.22
|
|
A00SO23
|
2•NO
|
0.14
|
0~0.5
(0~5)
|
|
A00SO23J
|
0.22
|
● Voltage/ AC110(50/60Hz), DC24V
● Wiring/Plug-in connector
Individual Wiring Type Manifold MFS☐-A00S
.
|
Type of Manifold
|
MFS☐-A00S
|
|
common SUP, common EXH, Ports on both sides
|
|
Port size
|
Port 1, 3
|
M5
|
|
Port 2
|
N3, M5
|
|
Number of stations
|
2~10
|
|
Mounting
|
Direct mount
|
|
Mountable Solenoid Valve
|
A00SO23, A00SO23J, A00SC23, A00SC23J
|
|
Blank plate
|
A00S-BP
|
